Getting around
- tap HOME
- VCF page: FREQ, RES, ENV, LFO. Also backs out of menus.
- tap EDIT
- Next page: VCF, VCF 2, DCO, DCO 2, ENV, LFO, ARP, FX.
- turn SELECT
- Step through the same 8 pages, both directions.
- turn KNOB 1
- KNOB 1-4 move the four sliders shown on the page.
- tap OCT-
- Octave down (OCT+ up), up to 2; lit when shifted.
Playing
- turn PRESETS
- Browse the 64 patches of the current bank (A11-A88).
- turn ALGORITHM
- Bank: FACT A, FACT B, USER A, USER B.
- tap ARP+turn KNOB 1
- Arpeggiator on / off; ARP lights while on.
- tap ARP+turn KNOB 2
- Arp MODE UP, U&D, DN; KNOB 3 rate, KNOB 4 octaves.
- tap SEL
- VCA mode ENV / GATE (organ-style on / off).
Sound
- tap HOME+turn KNOB 1
- Filter cutoff; KNOB 2 resonance (self-oscillates).
- tap HOME+turn KNOB 3
- Filter envelope amount; KNOB 4 filter LFO amount.
- tap HOME+tap EDIT
- VCF 2: KBD tracking, INV envelope, bend depths.
- tap HOME+EDIT twice
- DCO: RNG 16'/8'/4', PULSE, SAW, SUBSW on / off.
- tap ENV+turn SELECT
- One page left: DCO 2: SUB, NOISE, PWM, DCOLFO.
- tap ENV
- ENV (ADSR): ATK, DEC, SUS, REL.
- tap LFO
- LFO: RATE, DELAY, PWM MD (LFO or MAN).
Effects
- tap FX
- FX (CHORUS) page: CHO, HPF, VCA, LEVEL.
- tap FX+turn KNOB 1
- The Juno chorus: OFF, I, II, I+II; FX lights when on.
- tap FX+turn KNOB 2
- HPF: BST bass boost, FLT flat, 236 Hz, 754 Hz.
- tap FX+turn KNOB 4
- Patch output LEVEL.
Saving & loading
- tap SAVE
- Quick save: factory sound to first empty user slot; user slot overwritten.
- hold SAVE
- Half a second: SAVE PRESET screen; SAVE lights.
- hold SAVE+turn SELECT
- In it: choose the slot, UA11 to UB88.
- hold SAVE+turn ALGORITHM
- Move the name cursor; PRESETS changes the letter.
- hold SAVE+tap SAVE
- Commit the save; HOME leaves without saving.
- hold SAVE+SEL twice
- Delete the chosen user slot (second press confirms).
MIDI & sync
- tap GLO
- OPTIONS menu: MIDI SETUP, ABOUT; GLO again closes.
- tap GLO+tap SEL
- Open MIDI SETUP; SELECT picks CHANNEL or SYNC.
- tap GLO+tap SEL+turn ALGORITHM
- Change the chosen value (channel 1-16, sync).
Good to know
- Edits are lost when you turn PRESETS; tap SAVE first. Factory patches are never overwritten, a quick save goes to a user slot named *Name.
- An empty user slot (USER A / USER B) loads a plain saw init patch: a clean start for your own sound.
- The 106 classic: a saw or pulse pad with chorus II, or I+II for the fast vibrato-like shimmer.
- Over USB MIDI it plays on any channel and takes CCs: 74 cutoff, 71 resonance, 73/75/70/72 attack/decay/sustain/release, 1 DCO LFO, 64 sustain pedal. It is also a USB audio interface.
- Something wrong after an update? Hold OCT- while powering on: USB rescue screen for reinstalling. Holding OCT-, OCT+ and HOME for 5 s also enters UPDATE MODE.
A community cheat sheet by the hub, not by the firmware's makers: when in doubt, their manual is right.
