Getting around
- tap HOME
- Back to HOME: one creature per track.
- turn ALGORITHM
- Pick the track (T1-T4; T5-T6 need TRACKS 6).
- turn SELECT
- Scroll the pages of the section you are in.
- hold SEQ+turn PRESETS
- Jump through any page button's pages.
- tap OCT+
- In dialogs and action pages: YES / do it.
- tap OCT-
- In dialogs and action pages: NO / back.
- hold HOME
- Open the MENU; tap HOME closes it.
Playing
- turn PRESETS
- Browse sounds of every engine, then your user presets.
- turn KNOB 1
- KNOB 1-4 on HOME: the sound's four main controls.
- tap OCT-
- Keyboard octave down / up (-3 to +3).
- hold OCT-+tap OCT+
- Both together: octave back to 0.
- tap PLAY
- Start / stop.
- hold GLO+tap PLAY
- Restart from the top without stopping.
- hold GLO+turn SELECT
- Change the tempo (GLO + F4: tap tempo).
- hold GLO+tap F#3
- Mute T1 (black keys 1-6 = T1-T6).
- hold GLO+tap F3
- Solo T1 while held (F3-D4 = T1-T6).
- hold GLO+tap E4
- Unmute everything.
Sound
- hold EDIT+turn SELECT
- Roll a new variation; OCT+ keeps it, OCT- reverts.
- tap EDIT
- The engine's own pages (tap again: next page).
- hold EDIT+tap F3
- INIT: back to the engine's factory sound.
- hold EDIT+tap G3
- RECALL: the sound as the section stored it.
- tap ENV
- Envelope pages.
- hold LFO+turn KNOB 1
- Macros M1-M4 on KNOB 1-4; tap LFO to unlatch.
- hold SEL+tap C4
- Make C the song's root (any key works).
Sequencer / patterns
- tap HOME+turn SELECT
- GEN song generator: KNOB 1 genre, OCT+ makes a song.
- tap SEQ
- Sequencer; tap again for the next set of knobs.
- tap SEQ+turn SELECT
- Zoom PATTERN / BAR / STEP.
- tap REC
- Arm the track and record live (overdub).
- hold SEQ+turn SELECT
- Dice the sequence; OCT+ keeps, OCT- reverts.
- hold REC+tap F3
- Clear the selected track's steps, no dialog.
- hold REC+tap G3
- Metronome click: OFF / REC / ON.
- hold SEQ+tap REC
- Clear all sequences (asks first).
Effects
- hold FX+tap F3
- Punch-in effects while held (white keys F3-F5).
- hold FX+turn KNOB 1
- FILTER; KNOB 2 CRUSH, 3 THROW, 4 DEPTH.
- hold FX+tap F#3
- Mute T1 while held (black keys 1-6).
- hold FX
- Let go untouched: FX layer stays open; tap FX to close.
- hold FX+turn SELECT
- Dice the effects; OCT+ keeps, OCT- reverts.
- tap FX
- FX pages; SELECT zooms TRACK / BUSES / EFFECT.
Saving & loading
- tap SAVE+tap OCT++tap OCT+
- Stopped: save the sound as a user preset.
- tap SAVE+turn SELECT
- Left one detent: PROJECT, the four sections A-D.
- turn KNOB 1+turn KNOB 4+tap OCT+
- On PROJECT, stopped: pick section, arm SAVE, then name and OCT+.
- turn KNOB 3+tap OCT+
- On PROJECT: LOAD the picked section.
- hold SAVE+tap F3
- Play section A on the next bar (F3-B3 = A-D).
- hold SAVE+tap C4
- Store into section A while playing (C4-F4 = A-D).
- hold HOME
- MENU > SYSTEM > RESTORE LAST ON: reopen last session.
Recovery
- hold GLO+tap G4
- UNDO the last big change (again: redo).
- hold OCT-+hold OCT++power on
- HARDWARE CALIBRATION: teach each button and knob.
- hold OCT-+hold OCT+
- 5 seconds: update mode (let go to cancel).
Good to know
- Power-on starts at zero: T1 ANALOG, T2 FM6, T3 LOFI, T4 DRUM, empty sequences.
- Saving and loading need the transport stopped (STOP TO SAVE).
- SAVE-layer stores go to flash only when you stop: stop before switching off.
- On a DRUM track OCT changes how keys play: up = ratchets, down = short / ghost / flam.
- Only T1-T4 play by default; GLO > SYSTEM > TRACKS 6 wakes T5 and T6.
A community cheat sheet by the hub, not by the firmware's makers: when in doubt, their manual is right.
